Picture of 2904M5 - Flow Control Uni-Directional - Flow Control Fittings - 4mm Tube To M5 Male Thread - Brass

2904M5 - Flow Control Uni-Directional - Flow Control Fittings - 4mm Tube To M5 Male Thread - Brass

Manufacturer: Pneumax
Flow Control Uni-Directional - Flow Control Fittings - 4mm Tube To M5 Male Thread - Brass
SKU: 2904M5
Manufacturer part number: 301Z3527
  • SKU : 2904M5
  • Brand : Pneumax
  • Product Portfolio : Pneumatics
  • Product Family : Fittings & Adaptors
  • Product Group : Flow Control Fittings
  • Product Class : Speed Controller Elbow
  • Family Code : 29
  • Join : Tube to Male Thread
  • Material : Brass
  • From : 4mm Tube
  • To : M5 Male Thread
  • Fluid : Compressed Air
  • Operating Temperature : -20 to +70 degrees C
  • Suggested Tubes : TPU (Polyurethane), PA11/PA12 (Polyamide), TPE (Polyethilene), TPA (Polyurethane/Copolyester)
  • Applications : Pneumatic circuits, low pressure hydraulic applications, according to DIN 3861-3870 norms. Suitable for vacuum applications.
  • Temperatures and pressures usually depend by the technical features of the employed tubes, anyway it is suggested a limit working pressure of 15 bar and a temperature range between -20°C and +70°C
  • Tube Tolerances : Diam. between 4 and 10 mm +/- 0,05 Diam. from 12 mm +/- 0,1
  • Warranty : 12 Months
